ESP32 Bit Pirate

concrete targets

ESP32 module wiring and target-chip guides

Browse module and target-chip guides for CC1101, MCP2515 CAN, nRF24L01, W5500 Ethernet, SPI NOR flash, I2C/93Cxx EEPROM, SLE4442 smartcards, 1-Wire iButton and PN532 NFC/RFID. Each page connects ESP32 wiring, Bit Pirate protocols, recipes, supported boards and read-first reading and controlled writing.

Compare boardsOpen hardware
Cluster of radio modules, memory chips, smartcards and adapter boards.

wireless modules

Radio and wireless modules

Radio module pages focus on concrete chips and connect each part to ESP32 Bit Pirate protocols, recipes and board choices.

Sub-GHz radio module

CC1101 Sub-GHz module

CC1101 sub-GHz radio module.

Use a CC1101 Sub-GHz module with ESP32 Bit Pirate to scan activity, receive frames, record lab captures and connect RF workflows to recipes and supported boards.

  • scan
  • receive
  • record
  • Sub-GHz
2.4 GHz RF module

nRF24L01 RF24 module

nRF24L01 2.4 GHz RF module.

Use an nRF24L01 RF24 module with ESP32 Bit Pirate to configure radios, scan channels, send payloads and receive lab traffic.

  • RF24
  • scan
  • send
  • receive
FM and RDS module

Si4713 FM transmitter module

Si4713 FM transmitter module.

Use a Si4713 FM module with ESP32 Bit Pirate to wire FM/RDS hardware, scan bands and trace radio behavior during controlled lab experiments.

  • FM
  • RDS
  • scan
  • trace

field buses

Network and field-bus modules

These modules extend ESP32 Bit Pirate toward CAN, Ethernet and modem workflows where wiring, power and bus configuration matter as much as firmware commands.

CAN field bus module

MCP2515 CAN module

MCP2515 CAN bus module.

Use an MCP2515 CAN module with ESP32 Bit Pirate to wire CAN hardware, sniff frames, send controlled traffic and explore CAN workflows.

  • CAN
  • sniff
  • send
  • MCP2515
Wired network module

W5500 Ethernet module

W5500 Ethernet module.

Use a W5500 Ethernet module with ESP32 Bit Pirate for DHCP, ping, HTTP, raw TCP, nmap and Modbus-oriented wired network workflows.

  • Ethernet
  • DHCP
  • TCP
  • Modbus
UART modem target

SIMCom cellular AT modem

Cellular AT modem module with SIM socket.

Use ESP32 Bit Pirate with SIMCom AT modems such as SIM800, SIM900, SIM7600 or A7670 to open a UART shell, check registration, read SIM data and test SMS or USSD commands.

  • SIMCom
  • AT
  • UART
  • SIM

reading and writing

Memory and firmware targets

Embedded memory reading and writing often begins with a chip on the bench: identify it, open the right shell, probe it safely, back it up and only then consider writes.

Memory and firmware target

SPI NOR flash chip

SPI flash adapter board with memory chip socket.

Use ESP32 Bit Pirate with SPI NOR flash chips by opening the dedicated SPI flash shell for JEDEC probe, analysis, byte reads, dumps, search and controlled erase/write actions.

  • flash shell
  • JEDEC
  • analyze
  • SPI
I2C memory target

I2C EEPROM chip

24C02 I2C EEPROM chip.

Use ESP32 Bit Pirate with I2C EEPROM chips by scanning the bus, then opening the dedicated EEPROM shell to probe size, analyze contents, read bytes, dump EEPROM and recover stuck bus states.

  • I2C
  • EEPROM shell
  • probe
  • recover
Microwire memory target

93Cxx Microwire EEPROM

SPI flash adapter board used for small EEPROM chips.

Use ESP32 Bit Pirate with 93Cxx Microwire EEPROM chips by opening the 3-Wire EEPROM shell to probe x8/x16 organization, read bytes, dump EEPROM and perform controlled writes or erases.

  • 93Cxx
  • 3-Wire shell
  • probe
  • backup

NFC and 1-Wire

Smartcards, iButton and NFC targets

These pages cover simple physical targets where pinout, protocol choice and safe test scope are the main source of mistakes.

2-Wire smartcard target

SLE4442 smartcard

SLE4442 smartcard.

Use ESP32 Bit Pirate with SLE4442-style smartcards to probe ATR, read memory and check security status in controlled lab workflows.

  • SLE4442
  • smartcard
  • ATR
  • 2-Wire
1-Wire contact target

1-Wire iButton

1-Wire iButton token.

Use ESP32 Bit Pirate with 1-Wire iButton targets to read ROM IDs, verify presence pulses and debug Dallas key wiring in controlled lab workflows.

  • 1-Wire
  • iButton
  • ROM ID
  • read
NFC and RFID module

PN532 NFC/RFID module

PN532 NFC RFID board.

Use a PN532 NFC/RFID module with ESP32 Bit Pirate to wire I2C readers, read lab tags and test supported write workflows in controlled setups.

  • PN532
  • NFC
  • RFID
  • I2C

related guides

From target chip to Bit Pirate workflow

Modules describe the real target on the bench. Protocol pages explain the mode, board pages explain the ESP32-S3 host, recipes explain a concrete action, and web tools turn some workflows into browser-based tasks.

Related protocols

Find the bus or radio mode behind each module: SPI, I2C, CAN, RF24, Sub-GHz, Ethernet, 1-Wire and more.

Compatible boards

Choose the ESP32-S3 target that exposes the right pins, USB behavior and physical form factor.

Detailed recipes

Move from a module overview to task-level wiring, scan, read, write, receive and troubleshooting guides.

Browser web tools

Open Web Serial, SPI Flash Programmer, Logic Analyzer, BPIO2 and other tools from a compatible browser.
